Applications:
– Base plates for structural steel columns
– Electrical tower foundations
– Heavy machinery bedding
– Filling voids, cracks, or anchor bolt pockets in precast concrete
Key Advantages:
✔ Zero shrinkage – Prevents cracking and ensures full contact.
✔ Adjustable consistency – Modify flow with water content.
✔ Rapid early strength – Speeds up project timelines.
✔ Superior adhesion – Bonds tightly to concrete and steel.
Coverage:
Calculate required volume based on cross-sectional area and the **density of fresh grout (2.41 g/cm³)** for precise estimation.
Application Guide:
1. Surface Prep: Remove oil, dust, and contaminants. Rinse with water; eliminate standing moisture.
2. Mixing:
– Add 3.5–4 L of water per 25 kg bag to a clean mixer.
– Gradually pour in RW N Grout while mixing.
– Blend 3–5 minutes until homogeneous and air-free.
3. Placement: Pour continuously at a suitable height to ensure proper flow pressure.
4. Curing: Cover exposed surfaces with wet burlap to retain moisture until initial set. For optimal curing, use a curing compound.
Critical Notes:
⚠ Water temp must keep mortar between 5°C–35°C** – Excessively hot water causes bleeding/segregation.
⚠ Avoid over-vibration or re-tempering – Do not thin mixed grout or add extra water.
Technical Data:
– Appearance: Gray powder
– Specific gravity (powder): 1.75 g/cm³
– Specific gravity (fresh grout): 2.41 g/cm³
– Free expansion: 2–5%
– Permanent expansion: 0–0.5%
– Shelf life: 12 months in original packaging (store dry, frost-free).
– Packaging: 25 kg bags
Safety & Environment:
– Avoid contact with eyes, mouth, or food. Rinse immediately if exposed.
– Do not discard excess material into waterways or soil.
Quality Assurance:
Manufactured in compliance with international quality standards.
